XPOL-1-5G

The Lynx Enclosure
X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna
617 - 3800 MHz, 3.5dBi
POYNTING antennas provide reliable connectivity for small and large open office spaces in urban commercial environments, ensuring seamless communication and data access.
POYNTING antennas enable reliable IoT connectivity for industrial and commercial warehousing, ensuring seamless communication and automation for efficient inventory management.
POYNTING antennas ensure reliable connectivity for farmers in the field, enabling seamless communication and real-time data access on mobile devices for smart farming.
POYNTING antennas enable reliable IoT connectivity for smart farming, ensuring seamless communication, automation, and real-time data access for precision agriculture.
POYNTING antennas ensure reliable connectivity for urban and rural estates, providing seamless communication and internet access for residential and business applications.
POYNTING antennas provide reliable connectivity for suburban and rural estates, ensuring seamless internet access for homes located on the outskirts of the city.
617-3800 MHzview details below
3dBi±17km/11mi coverage*
Omni-Directional
2×2 MIMO or
4×4 MIMO
IP65Dust-tight & Water-resistant

Key Features

  • Exceptional performance over the main 4G/5G bands
  • High gain for the antenna size
  • Wideband 2x2 or 4x4 MIMO 4G/5G antenna
  • Backwards compatible 2G/3G/4G/LTE/5G antenna
  • Weather, dust and vandal resistant enclosure (IP 65)
Supported Connectivity Technologies



Datasheet Options
POYNTING Antenna Solution Finder
A-XPOL-0001-V2
A-XPOL-0001-V2,X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna,Omni-Directional 5G Antenna Featured Image
A-XPOL-0001-V2,X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna,Omni-Directional 5G Antenna Back View
A-XPOL-0001-V2,X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna,Omni-Directional 5G Antenna Front View
A-XPOL-0001-V2,X-Polarised, Omni-Directional, 2X2 LTE MIMO Antenna,Omni-Directional 5G Antenna Side View
Second-Generation Cross-Polarised MIMO Antenna for 5G & LTE

The XPOL-1-5G is Poynting’s second-generation “V2” version of its popular Cross Polarised (XPOL) 2x2 MIMO antenna, now with an available 4x4 MIMO variant for user-specific needs. The antenna has been completely redesigned with a new enclosure and improved antenna technology, enhancing performance across multiple frequency bands.

Expanded Frequency Coverage: Now includes the 3400 – 3800 MHz and 617 MHz bands, in addition to 617 – 960 MHz, 1700 – 2170 MHz, and 2300 – 2700 MHz.
Optimised Omni-Directional Radiation Patterns: Ensures consistent coverage in urban, rural, agricultural, and commercial areas.
Peak Gain of 4 dBi: Delivers strong signal reception across all supported frequency bands.
2x2 and 4x4 MIMO Options: Available in 2x2 MIMO configuration, with a 4x4 MIMO derivative for enhanced data throughput.
Robust & Weather-Resistant Design: IP65-rated enclosure protects against dust, water, and vandalism, making it suitable for harsh environments.

The XPOL-1-5G is a versatile, high-performance antenna designed to improve connectivity for 2G, 3G, 4G, and 5G applications, ensuring reliable and efficient network performance across various industries.

Ideal Applications

  • Outdoor antenna for Fixed Wireless Access (FWA)
  • Consumer LTE/5G internet connectivity
  • Industrial & Commercial LTE/5G deployments
  • Urban household reception enhancement
  • Power, Energy & Water telemetry access
  • Oil & Gas communication systems
  • Municipal & Government systems
  • Repeaters & coverage enhancement amplifiers

Technical Specifications for XPOL-1-5G

Additional information

Industry (Application)

, ,

Technology

Cellular Freq. Range

Frequency Band

, , , , , , , , , , ,

5G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

LTE/4G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Wi-Fi Standard

Product Configuration

Gain

Directionality

Mounting Type

, ,

Connectors

MIMO

,

Polarisation

Environmental

Cellular Ports

,

Product Options/Variants for XPOL-1-5G

SKU Connector Type COAX Cable Type / Length Colour
A-XPOL-0001-V2-21 SMA (m) HDF-195 / 5m White
A-XPOL-0001-V2-41 SMA (m) HDF-195 / 5m White

VSWR & Gain

Gain (excluding Cable Loss)

Technical Drawing

FAQ's & Articles

Downloadable Files

High Resolution Images

A-XPOL-0001-V2-21 Omni-Directional LTE Feature Image A-XPOL-0001-V2-21 Omni-Directional LTE Back View A-XPOL-0001-V2-21 Omni-Directional LTE Front View A-XPOL-0001-V2-21 Omni-Directional LTE Side View Download website images (low resolution)

General Information (Not Product Specific)

View Our Downloads Page for High-Res Images and moreView all POYNTING Certifications and Declarations

Shipping Details

SKU A-XPOL-0001-V2-21 EAN: 6009710920763 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 1.05kg
2.31lbs		 Packaged Dimensions: 270 x 190 x 100 mm
10.63 x 7.48 x 3.94 inch		 Master Box QTY: 20 Master Box Weight: 19.5kg
43lbs		 Master Box Dimensions: 550 x 390 x 500mm
21.65 x 15.35 x 19.68 inch		 Country of Origin: CN
SKU A-XPOL-0001-V2-41 EAN: 6009710920886 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 1.34kg
2.95lbs		 Packaged Dimensions: 270 x 190 x 100 mm
10.63 x 7.48 x 3.94 inch		 Master Box QTY: 20 Master Box Weight: 27.62kg
60.89lbs		 Master Box Dimensions: 550 x 390 x 500mm
21.65 x 15.35 x 19.68 inch		 Country of Origin: CN
SKU A-XPOL-0001-V2-21A-XPOL-0001-V2-41
EAN 60097109207636009710920886
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 1.05kg
2.31lbs		1.34kg
2.95lbs
Packaged Dimensions 270 x 190 x 100 mm
10.63 x 7.48 x 3.94 inch		270 x 190 x 100 mm
10.63 x 7.48 x 3.94 inch
Master Box QTY 2020
Master Box Weight 19.5kg
43lbs		27.62kg
60.89lbs
Master Box Dimensions 550 x 390 x 500mm
21.65 x 15.35 x 19.68 inch		550 x 390 x 500mm
21.65 x 15.35 x 19.68 inch
Country of Origin CNCN
