SWIRL-8-CPE

The Swirl Enclosure

617-960 MHz; 1427-1517 MHz; 1710-2700 MHz; 3400-6000 MHz6dBiOmni-Directional5G8×8 MIMO617-698 MHzIP69K-40°C to +80°C

X-Polarised, Omni-Directional 5G/LTE, Multi MIMO Antenna Array
617 - 6000MHz, 6dBi; Cellular 2x(4x4 MIMO) + Wi-Fi 4x4 (MIMO) + 1 x GNSS



  • High performance, omni-directional Maritime & Mobility Antenna
  • Up to 8 x 8 MIMO capability for improved performance
  • Covers contemporary 5G/LTE band from 617 to 6000 MHz
  • Innovative heat sink design for improved temperature regulation
  • UV and saltwater protected for marine and coastal applications
  • IP69K weather/dust resistant enclosure

Additional Benefits

  1. 1. Simplified Deployment: SWIRL-8-02 provides an all-in-one solution, simplifying the installation process by housing both the antenna array and the 5G router(s) in a single unit. This reduces setup complexity.
  2. Optimized Performance: Housing the router within the same enclosure as the antennas minimizes cable loss and improves signal integrity. This leads to better overall performance, especially in challenging environments where maintaining a stable connection is crucial.
  3. Router Housing: The SWIRL-BASE can accommodate router sizes of 231 x 193 x 50 mm / 9.094 x 7.60 x 1.97 inch or 293.5 x 148.5 x 50 mm / 11.56 x 5.85 x 1.97 inch.
  4. Compact Design: SWIRL-8-02 features a compact design with dimensions of 382 mm / 15.039 inch in diameter and 224 mm / 8.82 inch in height.
The SWIRL-8-02 builds upon the antenna array of the SWIRL-8-01 by adding an aluminum base, known as the SWIRL-BASE The SWIRL-BASE serves as an enclosure for 5G routers, transforming the SWIRL-8-02 into a Customer Premises Equipment (CPE) device, where the router and antennas are combined into a single unit.

Additional information

Industry (Application)

,

Technology

, ,

Cellular Freq. Range

Wi-Fi Freq. Bands

2400-2500mHz
5000-7200mHz

Frequency Band

, , , , , , , , , , , , , ,

5G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

LTE/4G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Wi-Fi Standard

, , , , ,

Product Configuration

Directionality

Gain

Mounting Type

,

MIMO

Connectors

Polarisation

Enclosure Name

Environmental

Enclosure Size

LTE Ports

Wi-Fi Ports

GNSS/GPS Ports

SKU COAX Cable Type COAX Cable Length Colour
A-SWIRL-0008-V1-02 RTK-031 0.65m White

SKU EAN: HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight: Packaged Dimensions: Master Box QTY: Master Box Weight: Master Box Dimensions: Country of Origin:
SKU EAN: HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight: Packaged Dimensions: Master Box QTY: Master Box Weight: Master Box Dimensions: Country of Origin:
SKU
EAN
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight
Packaged Dimensions
Master Box QTY
Master Box Weight
Master Box Dimensions
Country of Origin
