PUCK-8

698-960 MHz; 1710-2700 MHz; 3400-3800 MHzLTE: 6dBi; Wi-Fi: 7.5dBi Omni-Directional4G LTE5G Ready2.4-2.5 GHz 5.0-6.0 GHz2X2 MIMOIP 68

3-in-1 Transportation & IoT/M2M Antenna

698 – 3800 MHz; 2X2 LTE (MIMO), 6dBi; Wi-Fi (SISO), 7.5dBi

  • 3-in-1 high performance multi frequency
  • 2G/3G/4G/LTE antenna (5G Ready)
  • LTE (2X2 MIMO), Dual-band Wi-Fi (SISO)
  • Wideband – covers wide frequency band, incl. 3.5 GHz CBRS band
  • Ground plane independent
  • Robust, vandal resistant and waterproof (IP68)
  • Ideal for transportation, marine and IoT/M2M use
  • Ultra-versatile mounting options for easy installation




Closing tab trigger

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

Product Overview

Poynting’s new PUCK range offers a small profile antenna for use in the IoT/M2M, Smart Meter, Smart Utilities, Transportation, Marine and the Agricultural/Farming markets. The PUCK-8 consists of a 3-in-1 antenna system within a single housing, featuring 2×2 MIMO LTE and Wi-Fi (Dual-band 2.4 GHz & 5 GHz). The 2x Cellular MIMO antennas (for 2G/3G/4G) cover the 698 MHz to 3800 MHz band, this includes the most popular international LTE bands. The antenna provides a dual-band Wi-Fi antenna offering concurrent 2.4 GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax. The PUCK exceeds the performance of many competitors due to the attention to design of this high-performance antenna. The radiation patterns of all radiating elements provide an excellent balance between omnidirectionality, pattern diversity and good radiation abilities at the desired elevation, which is often overlooked in such a small size antenna. Despite its small size, this antenna provides excellent performance especially at the higher frequency bands, where performance is critical for LTE throughput and connection stability. This antenna is designed so that both the LTE ports are connected to the router/device to ensure the best performance. Please see other derivatives of the PUCK range that are more suitable for a SISO application.

Product Options

SKU A-PUCK-0008-V1-01
Coax Cable Type RTK-031
Coax Cable Length 2.00m
Connector Type SMA (m) & RPSMA adaptors
Colour Black

Shipping Details

SKU A-PUCK-0008-V1-01
EAN 6009710920510
HS Code #85291069
Packaged Weight 0.557kg
Packaged Dimensions 150 x 150 x 120 mm
Master Box QTY 27
Master Box Weight 18.03kg
Master Box Dimensions 520 x 495 x 400 mm
Country of Origin China

PUCK-8

3-in-1 Transportation & IoT/M2M Antenna

698 – 3800 MHz; 2X2 LTE (MIMO), 6dBi; Wi-Fi (SISO), 7.5dBi

698-960 MHz; 1710-2700 MHz; 3400-3800 MHzLTE: 6dBi; Wi-Fi: 7.5dBi Omni-Directional4G LTE5G Ready2.4-2.5 GHz 5.0-6.0 GHz2X2 MIMOIP 68

  • 3-in-1 high performance multi frequency
  • 2G/3G/4G/LTE antenna (5G Ready)
  • LTE (2X2 MIMO), Dual-band Wi-Fi (SISO)
  • Wideband – covers wide frequency band, incl. 3.5 GHz CBRS band
  • Ground plane independent
  • Robust, vandal resistant and waterproof (IP68)
  • Ideal for transportation, marine and IoT/M2M use
  • Ultra-versatile mounting options for easy installation
Closing tab trigger

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

Product Overview

Poynting’s new PUCK range offers a small profile antenna for use in the IoT/M2M, Smart Meter, Smart Utilities, Transportation, Marine and the Agricultural/Farming markets. The PUCK-8 consists of a 3-in-1 antenna system within a single housing, featuring 2×2 MIMO LTE and Wi-Fi (Dual-band 2.4 GHz & 5 GHz). The 2x Cellular MIMO antennas (for 2G/3G/4G) cover the 698 MHz to 3800 MHz band, this includes the most popular international LTE bands. The antenna provides a dual-band Wi-Fi antenna offering concurrent 2.4 GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax. The PUCK exceeds the performance of many competitors due to the attention to design of this high-performance antenna. The radiation patterns of all radiating elements provide an excellent balance between omnidirectionality, pattern diversity and good radiation abilities at the desired elevation, which is often overlooked in such a small size antenna. Despite its small size, this antenna provides excellent performance especially at the higher frequency bands, where performance is critical for LTE throughput and connection stability. This antenna is designed so that both the LTE ports are connected to the router/device to ensure the best performance. Please see other derivatives of the PUCK range that are more suitable for a SISO application.

Product Options

SKU A-PUCK-0008-V1-01
Coax Cable Type RTK-031
Coax Cable Length 2.00m
Connector Type SMA (m) & RPSMA adaptors
Colour Black

Shipping Details

SKU A-PUCK-0008-V1-01
EAN 6009710920510
HS Code #85291069
Packaged Weight 0.557kg
Packaged Dimensions 150 x 150 x 120 mm
Master Box QTY 27
Master Box Weight 18.03kg
Master Box Dimensions 520 x 495 x 400 mm
Country of Origin China
