PUCK-7-V2

The PUCK Enclosure

617-960 MHz; 1427-1517MHz; 170-2700 MHz; 3400-4200 MHz; 5000-6000MHzLTE: 6.5dBi; Wi-Fi: 6dBi Omni-Directional5G617-698 MHz2.4-2.5 GHz 5.0-7.2 GHz2×2 MIMOIP69K

4-in-1 Transportation & IoT/M2M Antenna
617 - 6000 MHz; 2X2 5G (MIMO), 6.5 dBi; 2400 - 7200 MHz, 2X2 Wi-Fi (MIMO), 6dBi
  • 4-in-1 5G high performance multi frequency antenna
  • Antenna supports Private 5G/5G/4G/3G/2G/Wi-Fi-6e/ Wi-Fi-7/LoRa/Bluetooth
  • 5G (2x2 MIMO) and Dual-band Wi-Fi (2x2 MIMO)
  • Ultra-wideband coverage from 617 – 6000 MHz for cellular
  • Robust, vandal resistant and waterproof (IP 69K)
  • Ideal for transportation, marine and IoT/M2M use
  • Ultra-versatile mounting options for easy installation
Poynting’s new PUCK range offers a small profile antenna for use in the IoT/M2M, Smart Meter, Smart Utilities, Transportation, Marine and the Agricultural/Farming markets. The PUCK-7 consists of a 4-in-1 antenna system within a single housing, featuring 2x2 MIMO 5G and 2x2 MIMO Wi-Fi (Dual-band 2.4GHz & 5GHz) The 2x Cellular MIMO antennas (for 2G/3G/4G and 5G) offer wideband coverage from 617 to 6000 MHz, covering contemporary LTE/4G and 5G bands for future-proof implementation. The ultra-wideband performance of the cellular antennas allows it to be used across different operators and technologies and is ready for future cellular technologies up to 6 GHz for 5G applications. The antenna provides two separate dual-band Wi-Fi antennas offering concurrent 2.4GHz, 5GHz and 6GHz bands, capable of 802.11n and 802.11ac/ax/be with 2x2 MIMO. The PUCK exceeds the performance of many competitors due to the attention to design of this high-performance antenna. The radiation patterns of all radiating elements provide an excellent balance between omnidirectionality, pattern diversity and good radiation abilities at the desired elevation, which is often overlooked in such a small size antenna. Despite its small size, this antenna provides excellent performance especially at the higher frequency bands, where performance is critical for 5G and LTE throughput and connection stability. This antenna is designed so that both the 5G/LTE ports are connected to the router/device to ensure the best performance. Please see other derivatives of the PUCK range that are more suitable for a SISO application.

SKU COAX Cable Type COAX Cable Length Colour Other
A-PUCK-0007-V2-01 RTK-031 2m Black

SKU A-PUCK-0007-V2-01 EAN: 6009710928318 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight: 0.65kg
1.43lbs
Packaged Dimensions: 150 x 150 x 120 mm
5.91 x 5.91 x 4.73 inch
Master Box QTY: 27 Master Box Weight: 17.25kg
38.03lbs
Master Box Dimensions: 520 x 495 x 400 mm
20.47 x 19.49 x 15.75 inch
Country of Origin: CN
SKU A-PUCK-0007-V2-01
EAN 6009710928318
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 0.65kg
1.43lbs
Packaged Dimensions 150 x 150 x 120 mm
5.91 x 5.91 x 4.73 inch
Master Box QTY 27
Master Box Weight 17.25kg
38.03lbs
Master Box Dimensions 520 x 495 x 400 mm
20.47 x 19.49 x 15.75 inch
Country of Origin CN
