HELI-19

The MiniHELI Enclosure
Circular Polarised, Bi-Directional Mine/Tunnel Antenna; Dual-band Wi-Fi
2400 - 2500 MHz, 9dBic; 5000 - 6000 MHz, 11dBic
POYNTING antennas ensure reliable connectivity for busy subway trains, providing seamless communication and internet access in underground tunnels and high-traffic urban environments.
POYNTING antennas ensure reliable connectivity for underground mining trucks, enabling seamless communication and data transmission in tunnel environments.
POYNTING antennas deliver robust connectivity for high-traffic subway trains, ensuring seamless communication and internet access in underground and tunnel environments.
POYNTING antennas provide reliable connectivity for IoT-enabled open-pit mining, supporting seamless communication for unmanned trucks and autonomous vehicles in rugged environments.
POYNTING antennas enable reliable IoT connectivity for underground mining operations, ensuring seamless communication, automation, and data transmission in challenging environments.
POYNTING antennas ensure reliable connectivity for underground mining, enabling seamless communication and data access for miners using digital devices and autonomous trucks.
2400-2500 MHz; 5000-6000 MHzview details below
2.4GHz 9dBic; 5GHz 11dBic±11km/7mi coverage*
Bi-Directional
2.4-2.5 GHz 5.0-6.0 GHz
2×2 MIMO Possible with RHC & LHC combined
IP65Dust-tight & Water-resistant
-40°C to +70°C
Fire Resistant
(TRG) MDG 3608:2022

Key Features

  • Circular Polarised HELI antenna provides enhanced signal propagation and connection stability within a tunnel
  • Left Hand Circular (LHC) & Right-Hand Circular (RHC) Polarised options available
  • Bi-directional – radiates in both directions in a tunnel
  • Ruggedized, water and dust ingress protected (IP 65)
  • Ideal for Mining & Tunnel M2M and IoT deployments
Supported Connectivity Technologies


Datasheet Options
POYNTING Antenna Solution Finder
A-HELI-0019-V3-01
A-HELI-0019-V3-01,Circular Polarised, Bi-Directional Mine/Tunnel Antenna; Dual-band Wi-Fi,Wi-Fi Mine Tunnel Featured Image
A-HELI-0019-V3-01,Circular Polarised, Bi-Directional Mine/Tunnel Antenna; Dual-band Wi-Fi,Wi-Fi Mine Tunnel Back View
A-HELI-0019-V3-01,Circular Polarised, Bi-Directional Mine/Tunnel Antenna; Dual-band Wi-Fi,Wi-Fi Mine Tunnel Front View
A-HELI-0019-V3-01,Circular Polarised, Bi-Directional Mine/Tunnel Antenna; Dual-band Wi-Fi,Wi-Fi Mine Tunnel Side View
Bi-Directional Dual-Band 2.4 GHz & 5 GHz Wi-Fi Antenna for IoT and Mining Tunnels

The HELI-19 is part of Poynting’s Mini-HELI series, designed to provide reliable dual-band 2.4 GHz and 5 GHz Wi-Fi connectivity in mining tunnels where IoT and M2M communication is essential. Despite its compact size compared to larger models like the HELI-3, HELI-4, and HELI-8, the HELI-19 delivers medium to high gain performance, making it ideal for coverage into stopes and throughout tunnel environments. This bi-directional antenna radiates signals in both directions, ensuring optimal tunnel-wide Wi-Fi coverage for telemetry, mine automation, and IoT deployments.

Optimized for Tunnel Communications: Supports dual-band 2.4 GHz and 5 GHz Wi-Fi, ensuring reliable coverage for mining and industrial tunnels.
Bi-Directional Design: Provides signal coverage in both directions, making it ideal for long tunnels and extended connectivity.
MIMO-Optimized Deployment: Available in Left-Hand Circular (LHC) and Right-Hand Circular (RHC) polarisation, enhancing MIMO performance when used with the BRKT-45 mount.
Non-Line of Sight (NLOS) Propagation: Wi-Fi signals can propagate around tunnel bends, overcoming obstacles such as mining equipment and trains.
Enhanced RF Reliability: Reduces signal degradation caused by metallic surfaces, machinery, and tunnel curvature.
Compact and Durable Construction: Engineered for harsh underground conditions, ensuring long-term reliability in mining environments.

The HELI-19 is an ideal solution for mining tunnels, delivering reliable, bi-directional dual-band Wi-Fi connectivity to support industrial automation, IoT, and M2M applications in demanding underground environments.

Ideal Applications

  • Supplementing fibre/leaky feeder cable “Hotspots” to areas to enhance mobility or extend networks to inaccessible areas
  • Underground telemetry and automation
  • Creating of complete underground in tunnel wide data networks and internet/LTE connectivity
  • Seamless connection to personnel using cellular phones and smart devices and tablets

Technical Specifications for HELI-19

Additional information

Industry (Application)

Technology

Cellular Freq. Range

Frequency Band

,

Wi-Fi Standard

, , ,

Product Configuration

Gain

Directionality

Mounting Type

Connectors

MIMO

Polarisation

Environmental

Wi-Fi Ports

Accessories

Product Options/Variants for HELI-19

SKU Connector Type COAX Cable Type / Length Colour
A-HELI-0019-V3-01-L N-Type (m) RG-141 / 0.6m Grey
A-HELI-0019-V3-01-R N-Type (m) RG-141 / 0.6m Grey

VSWR & Gain

Gain (excluding Cable Loss)

Technical Drawing

FAQ's & Articles

Downloadable Files

HELI-19 Product Certificates

A-HELI-0019-V2-01-L Declaration of Conformity A-HELI-0019-V2-01-R Declaration of Conformity A-HELI-0019-V2 FRAS Certification

High Resolution Images

A-HELI-0019-V2-01 Feature Image A-HELI-0019-V2-01 Back View A-HELI-0019-V2-01 Front View A-HELI-0019-V2-01 Side View A-HELI-0019-V3-01 Feature Image A-HELI-0019-V3-01 Back View A-HELI-0019-V3-01 Front View A-HELI-0019-V3-01 Side View A-HELI-0019-V3-01 Top View Download website images (low resolution)

General Information (Not Product Specific)

View Our Downloads Page for High-Res Images and moreView all POYNTING Certifications and Declarations

Shipping Details

SKU A-HELI-0019-V3-01-L EAN: 6009710921418 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 1.44kg
3.17lbs		 Packaged Dimensions: 660 x 165 x 140 mm
25.98 x 6.5 x 5.51 inch		 Master Box QTY: 12 Master Box Weight: 19.28kg
42.51lbs		 Master Box Dimensions: 1110 x 690 x 300 mm
43.7 x 27.17 x 11.82 inch		 Country of Origin: RSA
SKU A-HELI-0019-V3-01-R EAN: 6009710921425 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 1.44kg
3.17lbs		 Packaged Dimensions: 660 x 165 x 140 mm
25.98 x 6.5 x 5.51 inch		 Master Box QTY: 12 Master Box Weight: 19.28kg
42.51lbs		 Master Box Dimensions: 1110 x 690 x 300 mm
43.7 x 27.17 x 11.82 inch		 Country of Origin: RSA
SKU A-HELI-0019-V3-01-LA-HELI-0019-V3-01-R
EAN 60097109214186009710921425
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 1.44kg
3.17lbs		1.44kg
3.17lbs
Packaged Dimensions 660 x 165 x 140 mm
25.98 x 6.5 x 5.51 inch		660 x 165 x 140 mm
25.98 x 6.5 x 5.51 inch
Master Box QTY 1212
Master Box Weight 19.28kg
42.51lbs		19.28kg
42.51lbs
Master Box Dimensions 1110 x 690 x 300 mm
43.7 x 27.17 x 11.82 inch		1110 x 690 x 300 mm
43.7 x 27.17 x 11.82 inch
Country of Origin RSARSA
