The OMNI-494 is a high-performance cross-polarised dual-band Wi-Fi omni-directional antenna designed for marine and coastal applications. Covering the 2.4 GHz and 4.9 to 7.2 GHz bands, this antenna ensures seamless connectivity with both older Wi-Fi technologies and modern Wi-Fi 6E networks. With 4x4 MIMO capability, it provides superior wireless performance for demanding environments.
Dual-Band Wi-Fi Coverage: Supports 2.4 GHz and 4.9 – 7.2 GHz bands, ensuring compatibility with Wi-Fi 6E and future technologies. 4x4 MIMO Capability: Features vertically separated radiating elements for enhanced data throughput and network efficiency. Cross-Polarised Design: Includes high-gain vertically polarised antennas (9.8 dBi peak gain) and low-gain horizontally polarised antennas (4.5 dBi peak gain) for improved signal stability. True Omni-Directional Coverage: Provides 360° Wi-Fi connectivity, making it ideal for marine and coastal applications. Rugged Marine-Grade Construction: Built to withstand extreme weather conditions and high levels of RF noise. IP68 Protection Rating: Fully dustproof and waterproof, with foam-filled construction for durability in severe storms. Saltwater & UV Protection: UV-stable ASA radome resists corrosion, ensuring long-term durability in harsh marine environments. Versatile Deployment: Ideal for yachts, ships, offshore platforms, and other maritime installations requiring high-performance Wi-Fi.The OMNI-494 is a rugged and high-performance Wi-Fi antenna, designed to provide reliable and long-range wireless connectivity in extreme marine and coastal conditions. Its 4x4 MIMO design, cross-polarised elements, and durable construction make it the ultimate choice for demanding maritime deployments.
| Industry (Application) | |
|---|---|
| Technology | |
| Cellular Freq. Range | |
| Frequency Band | |
| 5G Bands | |
| Wi-Fi Standard | Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Product Configuration | |
| Gain | |
| Directionality | |
| Mounting Type | |
| Connectors | |
| MIMO | |
| Polarisation | |
| Environmental | |
| Wi-Fi Ports | |
| Accessories |
| SKU | Connector Type | COAX Cable Type / Length | Colour |
|---|---|---|---|
| A-OMNI-0494-V1-01 | SMA (M) & RPSMA adaptors | Twin HDF-195 / 2m | White |
| SKU | A-OMNI-0494-V1-01 | EAN: 6009710927441 | HS Code: 8529.10.69 (EU) 8517.71.0000 (USA) 8529.10.90 (SA & Global) |
Packaged Weight: 1.87kg 4.12lbs |
Packaged Dimensions: 704 x 147 x 100 mm 27.72 x 5.79 x 3.94 inch |
Master Box QTY: 10 | Master Box Weight: 20.29kg 44.73lbs |
Master Box Dimensions: 560 x 350 x 770 mm 22.05 x 13.78 x 30.32 inch |
Country of Origin: CN |
|---|---|---|---|---|---|---|---|---|---|
| SKU | A-OMNI-0494-V1-01 | ||||||||
| EAN | 6009710927441 | ||||||||
| HS Code | 8529.10.69 (EU) 8517.71.0000 (USA) 8529.10.90 (SA & Global) | ||||||||
| Packaged Weight | 1.87kg 4.12lbs | ||||||||
| Packaged Dimensions | 704 x 147 x 100 mm 27.72 x 5.79 x 3.94 inch | ||||||||
| Master Box QTY | 10 | ||||||||
| Master Box Weight | 20.29kg 44.73lbs | ||||||||
| Master Box Dimensions | 560 x 350 x 770 mm 22.05 x 13.78 x 30.32 inch | ||||||||
| Country of Origin | CN |
| Freq.: 2400 - 7200 MHz | |
| Peak Gain | |
| 9.8dBi | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
