XPOL-16

The Leopard Enclosure
X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO)
450 - 470 MHz, 6.5dBi; 790 - 2170 MHz, 8dBi
POYNTING antennas enable reliable IoT connectivity for electric vehicle charging stations, ensuring seamless communication and real-time data management for smart mobility solutions. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas ensure reliable connectivity for urban and rural estates, providing seamless communication and internet access for residential and business applications. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable connectivity for critical IoT applications in emergency services, ensuring seamless communication and data transmission for transport and mobility operations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas ensure reliable connectivity for commercial card machines, iot, enabling secure and seamless transactions in retail and business environments. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable connectivity for rural homes on the outskirts of urban areas, ensuring seamless internet access across large open spaces and farmland. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas ensure reliable connectivity in urban environments, providing seamless internet access for city applications. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
450-2170 MHzview details below
8dBi±42km/26mi coverage*
Directional
2×2 MIMO
IP65Dust-tight & Water-resistant
-40°C to +70°C

Key Features

  • Futureproof wideband LTE antenna
  • Includes the new 450 – 470 MHz frequency band
  • Backwards compatible with 3G and 2G technologies
  • Two antennas in one enclosure for optimal LTE performance
  • Improves mobile network subscriber’s user experience
  • Increased connectivity stability
  • Weather- and vandal resistant enclosure (IP 65)
Supported Connectivity Technologies



Datasheet Options
POYNTING Antenna Solution Finder
A-XPOL-0016
A-XPOL-0016,X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO),Directional LTE Featured Image
A-XPOL-0016,X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO),Directional LTE Back View
A-XPOL-0016,X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO),Directional LTE Front View
A-XPOL-0016,X-Polarised, High Gain, Uni-directional LTE Antenna (2X2 MIMO),Directional LTE Side View
Dual-Polarised LTE Antenna for Enhanced Signal Reception

The XPOL-16 is a high-performance LTE antenna designed to boost 4G, 3G, and 2G network signals. Covering multiple LTE frequency bands, including **450 – 470 MHz, 790 – 860 MHz, and 1710 – 2170 MHz**, this antenna enhances signal reception and throughput for improved connectivity. It features a dual-polarised, full LTE band design and is suitable for wall or pole mounting.

Multi-Band LTE Coverage: Supports 450 – 470 MHz, 790 – 860 MHz, and 1710 – 2170 MHz for enhanced 4G, 3G, and 2G connectivity.
Dual-Polarised MIMO Technology: Provides improved signal strength, stability, and increased data throughput.
Wall or Pole Mountable: Flexible mounting options for optimal positioning and signal reception.
Enhanced Network Reliability: Ensures higher data speeds, stable connections, and improved user experience.
Cost-Effective Solution: Designed to improve subscriber satisfaction while reducing network congestion.
Ideal for GSM-Based Applications: Compatible with LTE, HSPA, 3G, EDGE, and GPRS networks.

The XPOL-16 is a reliable and effective solution for enhancing mobile connectivity, ensuring improved performance and better user experience in various network applications.

Print Friendly, PDF & Email

Ideal Applications

  • Machine-to-Machine (M2M) applications
  • Urban and rural areas
  • Poor data signal reception (Indoor or outdoor)
  • Slow data transmission connectivity
  • Unstable connection
  • Increase system transmission reliability
  • LTE fringe areas (close to an LTE area, but just out of reach)
  • Network operator flexibility – as the antennas are wideband, a new antenna is not needed per network operator – works on most networks

Technical Specifications for XPOL-16

Additional information

Industry (Application)

,

Technology

,

Cellular Freq. Range

Frequency Band

, , ,

5G Bands

, , , , , , , , , , , , , ,

LTE/4G Bands

, , , , , , , , , , , , , , ,

Product Configuration

Gain

Directionality

Mounting Type

,

Connectors

MIMO

Polarisation

Environmental

LTE Ports

Product Options/Variants for XPOL-16

SKU Connector Type COAX Cable Type / Length Colour
A-XPOL-0016 SMA (m) HDF-195 / 5m Off White

VSWR & Gain

Gain (excluding Cable Loss)

Router Compatibilities

If you do not find your router brand or model below, you can use our POYNTING Antenna Solution Finder Tool to match it with the correct POYNTING antenna. Alternatively contact your closest partner for assistance.
Tip: Click on a model to view other POYNTING Antennas that are also compatible with that specific router.
Our database does not currently have a router that matches this antenna. You can use our POYNTING Antenna Solution Finder Tool to match it with the correct Poynting antenna. Alternatively contact your closest partner for assistance.
Advantech
Billion
EuroTech
Fritz!Box
Huawei
Peplink

Technical Drawing

FAQ's & Articles

No articles available currently.

Downloadable Files

High Resolution Images

A-XPOL-0016 Directional LTE Feature Image A-XPOL-0016 Directional LTE Back View A-XPOL-0016 Directional LTE Front View A-XPOL-0016 Directional LTE Side View Download website images (low resolution)

General Information (Not Product Specific)

View Our Downloads Page for High-Res Images and moreView all POYNTING Certifications and Declarations

Shipping Details

SKU A-XPOL-0016 EAN: 6009693810143 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 2.38kg
5.25lbs		 Packaged Dimensions: 360 x 360 x 98 mm
14.17 x 14.17 x 3.86 inch		 Master Box QTY: 7 Master Box Weight: 19.6kg
43.21lbs		 Master Box Dimensions: 400 x 500 x 610 mm
15.75 x 19.67 x 24.02 inch		 Country of Origin: CN
SKU A-XPOL-0016
EAN 6009693810143
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 2.38kg
5.25lbs
Packaged Dimensions 360 x 360 x 98 mm
14.17 x 14.17 x 3.86 inch
Master Box QTY 7
Master Box Weight 19.6kg
43.21lbs
Master Box Dimensions 400 x 500 x 610 mm
15.75 x 19.67 x 24.02 inch
Country of Origin CN
