GPS-1-V3

The PUCK Enclosure
GPS/GLONASS Active Antenna
1575.42/1602 MHz, 20dBi
POYNTING industrial warehousing application showing Wi-Fi connectivity for forklifts, AGVs, and automated systems. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
1575.42 MHz / 1602 MHzview details below
GPS: 20±3dBi
Omni-Directional
IP69KDust-tight & Waterproof
-40°C to +80°C
Fire Resistant
Chemical Protection

Key Features

  • GPS/GLONASS Active Antenna
  • Robust enclosure (IK10), vandal resistant and waterproof (IP69K)
  • Ideal for positioning and timing systems for transportation, marine and IoT/M2M applications
  • Ultra-versatile mounting options for easy installation
Supported Connectivity Technologies
Datasheet Options
POYNTING Antenna Solution Finder
A-GPS-0001-V3-01
A-GPS-0001-V3-01,GPS/GLONASS Active Antenna,GPS Antenna Back View
A-GPS-0001-V3-01,GPS/GLONASS Active Antenna,GPS Antenna Front View
A-GPS-0001-V3-01,GPS/GLONASS Active Antenna,GPS Antenna Side View
Compact & High-Precision GNSS Antenna for IoT & Transportation

POYNTING’s new V3 version of the GPS-1 antenna is a compact and reliable solution designed for IoT/M2M and transportation applications where precise positioning and timing are critical. The updated enclosure with an external seal ensures effortless implementation with multiple mounting options.

Accurate GPS/GLONASS Positioning: Supports 1575.42 MHz / 1602 MHz for enhanced satellite connectivity.
Compact & Low-Profile Design: Ideal for space-constrained IoT and M2M applications.
Reliable Performance in Extreme Conditions: Operates in temperatures as low as -40°C for dependable functionality in harsh environments.
Easy Installation: Features a new enclosure with versatile mounting options for seamless integration.

The GPS-1 V3 is the perfect solution for industries requiring **accurate navigation and timing**, offering durability, efficiency, and effortless deployment.

Print Friendly, PDF & Email

Ideal Applications

  • Industrial automation, robotic machinery and other M2M systems
  • Transport, tracking (Busses, Utility & Public Safety)
  • Mining Vehicles & Machinery communications and positioning (M2M & IoT)
  • Agricultural machinery
  • Marine: small boats, yachts.
  • Clocking and timing systems

Technical Specifications for GPS-1-V3

Additional information

Industry (Application)

,

Technology

Cellular Freq. Range

Gain

Directionality

Mounting Type

, , , ,

Connectors

MIMO

Polarisation

Environmental

GNSS/GPS Ports

Product Options/Variants for GPS-1-V3

SKU Connector Type COAX Cable Type / Length Colour
A-GPS-0001-V3-01 SMA (m) RTK-031 / 2m Black

Router Compatibilities

If you do not find your router brand or model below, you can use our POYNTING Antenna Solution Finder Tool to match it with the correct POYNTING antenna. Alternatively contact your closest partner for assistance.
Tip: Click on a model to view other POYNTING Antennas that are also compatible with that specific router.
Our database does not currently have a router that matches this antenna. You can use our POYNTING Antenna Solution Finder Tool to match it with the correct Poynting antenna. Alternatively contact your closest partner for assistance.

Technical Drawing

FAQ's & Articles

No articles available currently.

Downloadable Files

High Resolution Images

GPS-1-V3 Antenna Feature Image GPS-1-V3 Antenna Back View GPS-1-V3 Antenna Front View GPS-1-V3 Antenna Side View GPS-1-V3 Mounting Option: Panel GPS-1-V3 Mounting Option: Wall and Pole GPS-1-V3 Mounting Option: Spigot GPS-1-V3 Mounting Option: Spigot Exploded Long GPS-1-V3 Mounting Option: Spigot Exploded GPS-1-V3 Mounting Option: Surface Adhesive GPS-1-V3 Mounting Option: Magnetic Base Download website images (low resolution)

General Information (Not Product Specific)

View Our Downloads Page for High-Res Images and moreView all POYNTING Certifications and Declarations

Shipping Details

SKU A-GPS-0001-V3-01 EAN: 6009716250055 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 0.443kg
0.98lbs		 Packaged Dimensions: 150 x 150 x 120 mm
5.91 x 5.91 x 4.73 inch		 Master Box QTY: 27 Master Box Weight: 14.95kg
32.96lbs		 Master Box Dimensions: 520 x 495 x 400 mm
20.47 x 19.49 x 15.75 inch		 Country of Origin: RSA
SKU A-GPS-0001-V3-01
EAN 6009716250055
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 0.443kg
0.98lbs
Packaged Dimensions 150 x 150 x 120 mm
5.91 x 5.91 x 4.73 inch
Master Box QTY 27
Master Box Weight 14.95kg
32.96lbs
Master Box Dimensions 520 x 495 x 400 mm
20.47 x 19.49 x 15.75 inch
Country of Origin RSA
