Poynting’s PUCK range introduces a small-profile, high-performance antenna designed for IoT/M2M, Smart Metering, Smart Utilities, Transportation, Marine, and Agricultural/Farming applications. The PUCK-3 is a 3-in-1 antenna system within a single enclosure, providing reliable and future-proof connectivity for 5G, LTE, Wi-Fi, and GPS applications.
Wideband Cellular Coverage: Features a SISO Cellular antenna covering 617 to 6000 MHz, ensuring compatibility with 2G, 3G, 4G, and 5G networks. Dual-Band SISO Wi-Fi Connectivity: Supports 2.4 GHz, 5 GHz, and 6 GHz bands, compatible with 802.11n, 802.11ac/ax/be standards. High-Precision GPS/GLONASS Antenna: Active GPS system ensures accurate positioning, operational at temperatures as low as -40ºC. Future-Proof 5G and LTE Implementation: Ultra-wideband performance ensures seamless operation across different operators and evolving cellular technologies up to 6 GHz. Optimised Radiation Patterns: Provides a balance of omnidirectionality, pattern diversity, and reliable signal performance at the desired elevation. Compact & Versatile Design: Small form factor enables easy integration across multiple industries while maintaining high-performance capabilities.The PUCK-3 is an excellent choice for applications requiring a compact yet powerful antenna solution, delivering strong and stable 5G, LTE, Wi-Fi, and GPS connectivity.
| SKU | Connector Type | COAX Cable Type / Length | Colour |
|---|---|---|---|
| A-PUCK-0003-V2-01 | SMA (m) & RPSMA adaptors | RTK-031 / 2m | Black |
| SKU | A-PUCK-0003-V2-01 | EAN: 6009710928271 | HS Code: 8529.10.69 (EU) 8517.71.0000 (USA) 8529.10.90 (SA & Global) |
Packaged Weight: 0.65kg 1.43lbs |
Packaged Dimensions: 150 x 150 x 120 mm 5.91 x 5.91 x 4.73 inch |
Master Box QTY: 27 | Master Box Weight: 18.25kg 40.23lbs |
Master Box Dimensions: 520 x 495 x 400 mm 20.47 x 19.49 x 15.75 inch |
Country of Origin: CN |
|---|---|---|---|---|---|---|---|---|---|
| SKU | A-PUCK-0003-V2-01 | ||||||||
| EAN | 6009710928271 | ||||||||
| HS Code | 8529.10.69 (EU) 8517.71.0000 (USA) 8529.10.90 (SA & Global) | ||||||||
| Packaged Weight | 0.65kg 1.43lbs | ||||||||
| Packaged Dimensions | 150 x 150 x 120 mm 5.91 x 5.91 x 4.73 inch | ||||||||
| Master Box QTY | 27 | ||||||||
| Master Box Weight | 18.25kg 40.23lbs | ||||||||
| Master Box Dimensions | 520 x 495 x 400 mm 20.47 x 19.49 x 15.75 inch | ||||||||
| Country of Origin | CN |
| Freq.: 617 - 6000 MHz | |
| Peak Gain | |
| 5.5dBi(LTE) | |
| Pattern | Omni-Directional |
| MIMO | SISO |
| Freq.: 617 - 6000 MHz | |
| Peak Gain | |
| 6.5dBi(LTE), 6dBi(Wi-Fi) | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 6000 MHz | |
| Peak Gain | |
| 6.5dBi(LTE) | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 6000 MHz | |
| Peak Gain | |
| 6.5dBi(LTE), 21dBi(GPS) | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
