• High power global 3G/4G modem
• Optional WIFI Booster for long distance WIFI connection (10+ NM)
• 1x Vessel Network
• 5x Backbone or Vessel Network port (GbE)
• Network Extender support (max. 1)
• Online Remote support
• Free Remote Tracking and Anchor alarm
• Wide range DC power input (10-30 V)
• Compatible with Furuno, Simrad, Lowrance, B&G, Garmin, Maretron, Sonos, Apple Airplay and other IP based systems
| Freq.: 410 - 3800 MHz | |
| Peak Gain | |
| 5.8dBi(LTE), 7dBi(Wi-Fi), 21dBi(GPS) | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 410 – 4200 MHz | |
| Peak Gain | |
| 5.8dBi | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 3800 MHz | |
| Peak Gain | |
| 9dBi | |
| Pattern | Omni-Directional |
| MIMO | SISO |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
• High power global 3G/4G/5G modem
• 1x SAT port (Starlink, VSAT, Iridium, Inmarsat, mobile routers)
• Optional High power global 3G/4G/5G module via Mobile Expander s6
• Optional WIFI Booster for long distance WIFI connection (10+ NM)
• 2x Vessel Network (e.g. Crew, Guest)
• 4x Backbone or Vessel Network port (GbE)
• Extremely fast WIFI 6 (ax)
• Network Extender support (max. 5)
• Online Remote support
• Free Remote Tracking and Anchor alarm
• Wide range DC power input (10-30 V)
• Compatible with Furuno, Simrad, Lowrance, B&G, Garmin, Maretron, Sonos, Apple Airplay and other IP based systems
| Freq.: 410 – 4200 MHz | |
| Peak Gain | |
| 5.8dBi | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 3800 MHz | |
| Peak Gain | |
| 9dBi | |
| Pattern | Omni-Directional |
| MIMO | SISO |
| Freq.: 617 - 7200 MHz | |
| Peak Gain | |
| 6dBi(LTE), 6.5dBi(Wi-Fi), 21dBi(GPS) | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 7200 MHz | |
| Peak Gain | |
| 6dBi(LTE), 6.5dBi(Wi-Fi), 21dBi(GPS) | |
| Pattern | Omni-Directional |
| MIMO | 4x4 |
• 2x SAT port (Starlink, VSAT, Iridium, Inmarsat, mobile routers)
• Optional High power global 3G/4G/5G module via Mobile Expander s6 (max. 2)
• Optional WIFI Booster for long distance WIFI connection (10+ NM)
• 3x Vessel Network (e.g. Crew, Guest, Owner) via Network Extender
• 3x Backbone or Vessel Network port (GbE)
• 1x Backbone or Vessel Network port (10 GbE SFP+)
• Hotel type hotspot on one Vessel Network
• Online Remote support
• Free Remote Tracking and Anchor alarm
• Wide range DC power input (10-30 V)
• Compatible with Furuno, Simrad, Lowrance, B&G, Garmin, Maretron, Sonos, Apple Airplay and other IP based systems
| Freq.: 617 - 7200 MHz | |
| Peak Gain | |
| 9.5dBi | |
| Pattern | Omni-Directional |
| MIMO | 8x8 |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 4x4 |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 3dBi, 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 4x4 |
| Freq.: 617 - 3800 MHz | |
| Peak Gain | |
| 9dBi | |
| Pattern | Omni-Directional |
| MIMO | SISO |
• 4x SAT port (Starlink, VSAT, Iridium, Inmarsat, mobile routers)
• Optional High power global 3G/4G/5G module (30+ Nautical miles) via Mobile Expander s6 (max .4)
• Optional WIFI Booster for long distance WIFI connection (10+ NM)
• Optional Network Expander s6 Pro (24 or 48 GbE PoE ports, 4x 10GB SFP+ ports)
• 9x Vessel Network (e.g. Crew, Guest, Owner etc)
• 4x Backbone port (GbE)
• 1x Backbone port (10 GbE SFP+)
• Hotel type hotspot on one Vessel Network
• Online Remote support
• Free Remote Tracking and Anchor alarm
• Wide range DC power input (10-30 V)
• Compatible with Furuno, Simrad, Lowrance, B&G, Garmin, Maretron, Sonos, Apple Airplay and other IP based systems
| Freq.: 617 - 3800 MHz | |
| Peak Gain | |
| 9dBi | |
| Pattern | Omni-Directional |
| MIMO | SISO |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 2x2 |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 3dBi, 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 4x4 |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 8dBi | |
| Pattern | Omni-Directional |
| MIMO | 4x4 |
| Freq.: 617 - 7200 MHz | |
| Peak Gain | |
| 9.5dBi | |
| Pattern | Omni-Directional |
| MIMO | 16x16 |
| Freq.: 617 - 4200 MHz | |
| Peak Gain | |
| 11dBi | |
| Pattern | Multi-Directional |
| MIMO | 4x4 |
