OMNI-300

The Mamba Enclosure
Omni-Directional, LoRa/Helium/IoT Antenna
868 - 930 MHz, 4.5dBi
868 – 930 MHzview details below
4.5dBi±15km/9mi coverage*
Omni-Directional
IP65Dust-tight & Water-resistant
-40°C to +70°C

Key Features

  • Omni-directional antenna with medium gain
  • Covers thee 868 MHz to 930 MHz band for IoT/M2M deployment
  • Covers the LoRa and ISM frequency bands
  • Popular choice for installers due to its versatility
  • Vandal and water-resistant enclosure (IP65)
Supported Connectivity Technologies

A-OMNI-0300-V2-01
Omni-Directional Medium-Gain Antenna for LoRa & IoT Applications

The OMNI-300 is a high-performance omni-directional antenna designed for Machine-to-Machine (M2M) and Internet of Things (IoT) applications. Covering the 868 to 930 MHz frequency bands, it is ideal for LoRa and ISM band communications, enabling long-distance connectivity. With medium gain performance, this antenna enhances signal reliability, increases data throughput, and ensures a stable, high-quality connection.

Wide Frequency Coverage: Supports 868 to 930 MHz, optimized for LoRa, ISM, and other long-range IoT applications.
Omni-Directional Design: Provides 360° signal coverage, ensuring reliable connectivity in all directions.
Enhanced Signal Stability: Improves data throughput and maintains strong network performance for IoT deployments.
Versatile Mounting Options: Can be wall or pole-mounted, offering flexibility for different installation environments.
Rugged Outdoor Durability: IP65-rated for dust and water resistance, making it ideal for outdoor applications.
Easy Integration: Comes with an N-Type (female) connector for seamless connectivity with various devices.

The OMNI-300 is a reliable and efficient antenna for IoT and M2M communication, delivering long-range, stable connectivity for smart cities, industrial automation, and remote monitoring applications.

Ideal Applications

  • M2M applications where machines and measurement devices need to be connected for real time monitoring
  • Utilities for power and water metering
  • Security industry where cameras and other security equipment needs to be monitored
  • Increase system transmission reliability

Technical Specifications for OMNI-300

Additional information

Industry (Application)

,

Technology

Cellular Freq. Range

Frequency Band

,

5G Bands

,

Product Configuration

Gain

Directionality

Mounting Type

,

Connectors

,

MIMO

Polarisation

Environmental

Cellular Ports

Product Options/Variants for OMNI-300

SKU Connector Type COAX Cable Type / Length Colour
A-OMNI-0300-V2-01 N-Type (f) N/A / N/A White
A-OMNI-0300-V2-02 RP-SMA (m) HDF-195 / 5m

VSWR & Gain

Gain (excluding Cable Loss)

Technical Drawing

Shipping Details

SKU A-OMNI-0300-V2-01 EAN: 6009710922033 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight: 0.51kg
1.12lbs
Packaged Dimensions: 595 x 130 x 65 mm
23.43 x 5.12 x 2.56 inch
Master Box QTY: 20 Master Box Weight: 10.2kg
22.49lbs
Master Box Dimensions: 610 x 545 x 352 mm
24.02 x 21.46 x 13.86 inch
Country of Origin: CN
SKU A-OMNI-0300-V2-02 EAN: 6009710924310 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight: 0.60kg
1.32lbs
Packaged Dimensions: 595 x 130 x 65 mm
23.43 x 5.12 x 2.56 inch
Master Box QTY: 20 Master Box Weight: 11.62kg
25.62lbs
Master Box Dimensions: 610 x 545 x 352 mm
24.02 x 21.46 x 13.86 inch
Country of Origin: CN
SKU A-OMNI-0300-V2-01A-OMNI-0300-V2-02
EAN 60097109220336009710924310
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 0.51kg
1.12lbs
0.60kg
1.32lbs
Packaged Dimensions 595 x 130 x 65 mm
23.43 x 5.12 x 2.56 inch
595 x 130 x 65 mm
23.43 x 5.12 x 2.56 inch
Master Box QTY 2020
Master Box Weight 10.2kg
22.49lbs
11.62kg
25.62lbs
Master Box Dimensions 610 x 545 x 352 mm
24.02 x 21.46 x 13.86 inch
610 x 545 x 352 mm
24.02 x 21.46 x 13.86 inch
Country of Origin CNCN
