LPDA-92

The LPDA Enclosure
Wideband Log-Periodic Dipole Array Antenna
698 - 3800 MHz, 11dBi
POYNTING antennas provide reliable connectivity for rural farming, ensuring seamless communication between homes, silos, warehouses, and smart agricultural operations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable IoT connectivity for rural wind farms, ensuring seamless communication, monitoring, and automation for efficient energy production. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable connectivity for rural farming, ensuring seamless communication between silos, warehouses, and smart agricultural operations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable connectivity for rural houses, ensuring seamless internet access and communication in remote locations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas provide reliable connectivity for rural houses, ensuring seamless internet access and communication in remote locations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
POYNTING antennas ensure reliable connectivity in rural open fields, providing seamless communication and internet access for agricultural and remote operations. Images are used for visual representation purposes only. These images may not be downloaded, copied, or used in any form without prior permission.
698-3800 MHzview details below
11dBi±38km/24mi coverage*
Directional
IP 65
-40°C to +70°C
Fire Resistant

Key Features

  • Futureproof wideband LTE and Wi-Fi antenna covering 698 – 3800 MHz
  • Compatible with 2G, 3G, 4G and 5G technologies
  • Covers the CBRS Band from 3.2 GHz to 3.8 GHz
  • Improves mobile network subscriber’s user experience
  • Weather- and vandal resistant
  • Used in extreme weather environment
Supported Connectivity Technologies




Datasheet Options
POYNTING Antenna Solution Finder
A-LPDA-0092
A-LPDA-0092,Wideband Log-Periodic Dipole Array Antenna,4G LTE Featured Image
A-LPDA-0092,Wideband Log-Periodic Dipole Array Antenna,4G LTE Back View
A-LPDA-0092,Wideband Log-Periodic Dipole Array Antenna,4G LTE Front View
A-LPDA-0092,Wideband Log-Periodic Dipole Array Antenna,4G LTE Side View
High-Gain Wideband Directional Antenna for Reliable Cellular & Wireless Connectivity

This high-gain, wideband, directional antenna is designed to cover all international cellular, mobile, and wireless data bands, including GSM 900, GSM 1800, UMTS, and LTE. It also supports extended cellular and WiMAX bands, such as the European/USA Digital Dividend bands and the 2.3–2.7 GHz licensed and unlicensed data bands, ensuring compatibility with various wireless communication systems.

Ultra-Wideband Coverage: Supports GSM, UMTS, LTE, and WiMAX bands, ensuring seamless connectivity.
Consistent High-Gain Performance: Delivers reliable signal strength across all supported frequencies.
Optimised for Wireless Communication Systems: Ideal for use in LTE, HSPA, 3G, EDGE, and GPRS networks.
Proven Reliability: Successfully deployed in extreme weather conditions across Africa and Europe with near-zero failure rates.
Ideal for Challenging Signal Environments: A trusted solution in areas where network operators face signal challenges.

This high-performance antenna is the perfect choice for enhancing mobile and wireless data connectivity, offering robust and reliable performance in even the most demanding environments.

Ideal Applications

  • Urban and rural areas
  • Antenna of choice for rural areas due to high gain
  • Poor data signal reception (indoor or outdoor)
  • Slow data transmission connection
  • Unstable connection
  • Increase system transmission reliability
  • LTE fringe areas (close to an LTE area, but out of reach)
  • Network operator flexibility – as the antennas are wideband, a new antenna is not needed per network operator – works on most networks

Technical Specifications for LPDA-92

Additional information

Industry (Application)

,

Technology

Cellular Freq. Range

Frequency Band

, , , , , , , , , ,

5G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

LTE/4G Bands

, , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,

Wi-Fi Standard

Product Configuration

Gain

Directionality

Mounting Type

Connectors

,

MIMO

,

Polarisation

Environmental

Cellular Ports

Accessories

Product Options/Variants for LPDA-92

SKU Connector Type COAX Cable Type / Length Colour
A-LPDA-0092 SMA (m) HDF-195 / 7m Silver
A-LPDA-0092-04 N-Type (f) HDF-195 / 0.3m Silver
A-LPDA-0092-04-LTE N-Type (f) HDF-195 / 0.5m Silver
A-LPDA-0092 N-Type (f) HDF-195 / 0.3m Silver
A-LPDA-0092-30-LTE SMA (m) HDF-195 / 7m Silver

VSWR & Gain

Gain (excluding Cable Loss)

Router Compatibilities

If you do not find your router brand or model below, you can use our POYNTING Antenna Solution Finder Tool to match it with the correct POYNTING antenna. Alternatively contact your closest partner for assistance.
Tip: Click on a model to view other POYNTING Antennas that are also compatible with that specific router.
Advantech
Celerway
Cradlepoint
Digi
Robustel
Teltonika

Technical Drawing

FAQ's & Articles

Downloadable Files

High Resolution Images

A-LPDA-0092-4G LTE Feature Image A-LPDA-0092-4G LTE Back View A-LPDA-0092-4G LTE Front View A-LPDA-0092-4G LTE Side View A-LPDA-0092-4G LTE Double Mounting Featured Image A-LPDA-0092-4G LTE Double Mounting Back Image A-LPDA-0092-4G LTE Double Mounting Front Image A-LPDA-0092-4G LTE Double Mounting Side Image Download website images (low resolution)

General Information (Not Product Specific)

View Our Downloads Page for High-Res Images and moreView all POYNTING Certifications and Declarations

Shipping Details

SKU A-LPDA-0092 EAN: 6009710921166 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 2.02kg
4.45lbs		 Packaged Dimensions: 1120 x 210 x 60 mm
44.09 x 8.27 x 2.36. inch		 Master Box QTY: 10 Master Box Weight: 20.02kg
44.14lbs		 Master Box Dimensions: 1140 x 435 x 330 mm
44.88 x 17.13 x 13 inch		 Country of Origin: RSA
SKU A-LPDA-0092-04 EAN: 6009710921722 HS Code: 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		 Packaged Weight: 1.93kg
4.25lbs		 Packaged Dimensions: 1120 x 210 x 60 mm
44.09 x 8.27. x 2.36.inch		 Master Box QTY: 10 Master Box Weight: 19.37kg
42.7lbs		 Master Box Dimensions: 1125 x 430 x 330 mm
44.29 x 16.93 x 13 inch		 Country of Origin: CN
SKU A-LPDA-0092A-LPDA-0092-04
EAN 60097109211666009710921722
HS Code 8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)		8529.10.69 (EU)
8517.71.0000 (USA)
8529.10.90 (SA & Global)
Packaged Weight 2.02kg
4.45lbs		1.93kg
4.25lbs
Packaged Dimensions 1120 x 210 x 60 mm
44.09 x 8.27 x 2.36. inch		1120 x 210 x 60 mm
44.09 x 8.27. x 2.36.inch
Master Box QTY 1010
Master Box Weight 20.02kg
44.14lbs		19.37kg
42.7lbs
Master Box Dimensions 1140 x 435 x 330 mm
44.88 x 17.13 x 13 inch		1125 x 430 x 330 mm
44.29 x 16.93 x 13 inch
Country of Origin RSACN
