LPDA-92

The LPDA Enclosure
A-LPDA-0092 Wideband Log-Periodic Dipole Array Antenna; 698 - 3800 MHz, 11 dBi 4G LTE
A-LPDA-0092 Wideband Log-Periodic Dipole Array Antenna; 698 - 3800 MHz, 11 dBi 4G LTE
Technical Specification Download
698-960 MHz; 1710-2700 MHz; 3400-3800 MHz11dBiUni-Directional4G LTE5GIP 65-40°C to +70°CFire Resistant

Wideband Log-Periodic Dipole Array Antenna

698 - 3800 MHz, 11dBi

  • Futureproof wideband LTE and Wi-Fi antenna covering 698 – 3800 MHz
  • Compatible with 2G, 3G, 4G and 5G technologies
  • Covers the CBRS Band from 3.2 GHz to 3.8 GHz
  • Improves mobile network subscriber’s user experience
  • Weather- and vandal resistant
  • Used in extreme weather environment
Add to Compare
TS Document

Availability Notification

Availability Notification

Close Trigger
Product Overview

This high-gain, wideband, directional antenna covers all international cellular, mobile and wireless data bands including GSM 900/ GSM1800/UMTS/LTE bands. It also covers the extended cellular and WiMAX bands such as European/USA “Digital Dividend bands” and 2.3- 2.7GHz licensed and unlicensed data bands. Its configuration is suitable for various wireless communications systems. This antenna is unique in its combination of ultra-wide-band operator with a consistent high-gain performance. It has been successfully used in extreme weather environments in Africa and Europe with close to zero failures. A firm favourite, in any area where operators are having signal challenges. It is ideal for any application using the GSM network (LTE/ HSPA/3G/EDGE/GPRS).

Print Friendly, PDF & Email
Product Options
SKU A-LPDA-0092 A-LPDA-0092-04 A-LPDA-0092-04-LTE A-LPDA-0092 A-LPDA-0092-30-LTE
COAX Cable Type HDF-195 HDF-195 HDF-195 HDF-195 HDF-195
COAX Cable Length 7m 0.3m 0.5m 0.3m 7m
Color Silver Silver Silver Silver Silver
Product Video's
Webinar 7: Getting to the Poynt: Selecting an LTE Antennan Poynting LPDA-92 antenna 3D Radiation pattern LTE speed tests using B593 router and Poynting outdoor antennas (A-LPDA-0092)
Downloadable Files
Packing Check List -LPDA-92 A-LPDA-0092-4G LTE Feature Image A-LPDA-0092-4G LTE Back View A-LPDA-0092-4G LTE Front View A-LPDA-0092-4G LTE Side View View Our Downloads Page for High-Res Images and more
FAQ
Article - Top 5 Tips for investing in a good customer premises LTE or 5G antenna Article - Getting to the Poynt: Selecting an LTE Antenna FAQ - Which Antenna Do I Use With My LTE Router? Omni Vs Directional Antenna? FAQ - How to orientate a directional LTE antenna during installation? FAQ - How Do I Space 2 Single (SISO) Antennas For MIMO? Case Study - Poynting provides higher internet speeds and ‘fixed wireless’ access reliability in rural Wainui, Auckland, NZ Case Study - Inteto Connect solves cellphone reception problems at remote Game Farm Article - Are you ready for 5G: A selection of 5G ready antennas
Shipping Details
SKU A-LPDA-0092 A-LPDA-0092-04
EAN 6009710921166 6009710921722
HS Code #85291069 #85291069
Packaged Weight 2.02kg
4.45lbs		 1.93kg
4.25lbs
Packaged Dimensions 1120 x 210 x 60 mm
44.09 x 8.27 x 2.36 inch
Master Box QTY 10 10
Master Box Weight 20.02kg
44.14lbs		 19.37kg
42.7lbs
Master Box Dimensions 1140 x 435 x 330 mm
44.88 x 17.13 x 13 inch
Country of Origin RSA China
